Crosspatch Triggerpad


Give your unused USB MIDI controllers a second life and use them as sequencers for your Eurorack system!

The Triggerpad turns USB Midi controllers with an 8x8 grid into a trigger/gate sequencer. The controller is connected to the module via a USB cable and offers the ability to create and save patterns. The step length can be set individually for each channel from 1-64. This makes it possible to create polyrythmic sequences.

For a deeper understanding of the workflow, we suggest you watch the video linked below.

Available from spring 2024!

Features:

  • 8 channels (start/stop individually)
  • 1 to 64 steps pattern length (per channel)
  • 8 substeps per step (128th notes)
  • 7 levels of velocity of the trigger pulses (0-10V)
  • 250us – 1 step adjustable trigger/gate length
  • Session mode: record patterns quantized to substeps or 16th notes
  • Program sequences in step sequencer mode
  • Global and per channel shuffle
  • Program shuffle patterns: define which steps will be shuffled
  • Switch between patterns instantly or chain up to 64 patterns
  • Set the BPM from 0.5 to 400
  • Set clock divider and clock multiplier on clock input and output
  • No deep menu diving, tailored for live performance
  • Store and recall 64 snapshots of all 64 scenes on USB drives
  • Firmware updates possible via USB port on the rear panel

Inputs and outputs:

  • 8 dynamic trigger/gate outputs (0-10V)
  • USB MIDI Host
  • Clock in
  • Clock out
  • Reset in
  • Reset out

Compatibility:

  • Launchpad Pro Mk3
  • Launchpad X
  • Launchpad Mini Mk3
  • Launchpad Mini Mk2
  • Launchpad Pro
  • Launchpad Mk2
  • Launchpad S
  • APC Mini Mk1
  • APC Mini Mk2

345€

Power consumption: 120mA at +12V and 20mA at -12V (without USB MIDI controller connected)

USB MIDI controller draws additional up to 150 mA at +12 V

Depth: 39mm


6 HP
